Powder Paint

Powder coating is a guaranteed particles of pigment, resin, hardener, filler and additives that are electrostatic ally charged and sprayed on to substrates to be coated. The articles to be coated are electrically grounded so that the charged particles adhere to them and there after coated articles put in to oven for curing for certain time and temperature to get the required finish.

Advantages of Powder Coating:

Labour Saving : No dilution, ready to use, single coat application.

Material Saving : No loss of solvent and recycles upto 98% of the used powder.

Less pollution : Less pollution due to absence of losses.

Quality : Excellent mechanical, chemical corrosion resistance and good edged coverage.

Powder type & Covering Schedule

Film Properties:

1 Pure Epoxy MaTT 190-12 min metal temp
2 Epoxy Polystar (HYbird) Glossy, Semi-glossy satin text, Antiue 180-10 min metal temp
3 Pure Polystar Glossy, Semi-glossy 200-0 min metal temp

Film Properties:

Test Matt Satin Gloss
Gloss 2-20 50-60 85-95
Coating Thickness 50-60 50-60 50-60
Croess Hatch Adsivon GT-0 GT-0 GT-0
Bend test 6mm 4mm 3mm
pancil hardness 2h 2h 2h
Scratch resistace 2kg 2kg 2kg
Impact resistace
dirct 100kg cm 120kg cm 120kg cm
indirct 100kg cm 120kg cm 120kg cm
resistace 500hrus 500hrus 500hrus
humoi dary 500hrus 500hrus 500hrus
